Technical Detail
| Product Name | Classification | Mechanical Properties Of Weld Metal (Typical) | Unique Feature | TDS | |||||
| AWS/SFA | Yield Strength N/mm2 | Tensile Strength N/mm2(MIN) | Elongation 4D(%) | Impact (J) | Welding Conditions | ||||
| CELLULOSIC ELECTRODES | |||||||||
| 1 | GM 60 P | E 6010 | 380 | 510 | 24 | 47 at -30°C | DC(+) | A high cellulose sodium electrode with excellent penetration at all position. Best suitable for pipes and pipelines welding. Excellent mechanical properties in class. | Download |
| 2 | GM 60 PR | E 6011 | 380 | 515 | 24 | 47 at -30°C | AC;DC+ | A high cellulose potassium electrode with excellent penetration at all position. Best suitable for pipes and pipelines welding. Excellent mechanical properties in class. | Download |
| 3 | GM 70 P | E 7010 P1 | 415 | 490 | 22 | 27 at -30°C | AC;DC+ | Heavy Coated all postion electrode with cellulosic coating providing good welder appeal and smooth arc characterstic .This electrode has been specially deisgn for high yeild pipeline steels. | Download |
| RUTILE ELECTRODES | |||||||||
| 4 | GM 10 | E 6013 | 330 | 430 | 17 | NA | AC;DC+ | All position general purpose electrode with striking & restriking charecters | Download |
| 5 | GM 20 | E 6013 | 410 | 505 | 24 | 70 at 0°C | AC;DC+ | very soft arc, minimum spatter, smooth fine rippled radiographic weld bead. Superior slag detachablity. Excellent impact notch toughness at 0°C | Download |
| 6 | MODI XL 13S | E 6013 | 410 | 480 | 24 | 60 at 0°C | AC;DC+ | Ultra smooth weldability. Especially suited for thick section fillet joints. Excellent arc stability even at low current. | Download |
| 7 | GM 30 | E 6013 | 430 | 520 | 25 | 70 at 0°C | AC;DC+ | Ultra smooth weldability. Very smooth fusion with excellent slag detachability. Especially suited for thick section fillet joints. Excellent arc stability even at low current. | Download |
| 8 | GM 40 | E 6013 | 430 | 525 | 25 | 70 at 0°C | AC;DC+ | Rutile heavy coated, finely rippled smooth weld bead. Superior slag detachability. Excellent arc striking and restrinking. | Download |
| LOW HYDROGEN HIGH STRENGTH ELECTRODES | |||||||||
| 9 | GM 14 | E 7014 | 438 | 519.7 | 26 | 70 at -27°C | AC;DC+ | Heavy coated rutile type electrode with minimum 110% recovery | Download |
| 10 | GM 24 | E 7024 | 400 | 490 | 17 | NA | AC;DC+ | Rutile Base Super Heavy Coated Electrode with 130 min recovery ,suitable for Horizental & Fillet welding of heavier section with radiography qulaity. | Download |
| 11 | GM 16 | E 7016-H4 | 495 | 590 | 27 | 70 at -30°C | DC+;AC | Excellent weldability. Self peeling slag. Excellent mechanical Properties. | Download |
| 12 | GM 16 SPL | E 7016-1-H4 | 495 | 600 | 30 | 60 at -45°C | DC+;AC | Ultra Smoot finely ripled weld bead. Less than 4.0 ml diffusible hydrogen. Excellent impact notch toughness in class. | Download |
| 13 | GM 16-A1 | E 7016-A1-H4 | 480 | 595 | 26 | N/S | DC+;AC | Ultra Smoot finely ripled weld bead. Less than 4.0 ml diffusible hydrogen. Excellent for C- 0.50% Mo Steels. | Download |
| 14 | GM 18 | E 7018-H4 | 505 | 605 | 28 | 80 at -30°C | AC:DC+ | Excellent weldabillity. Best in Class mechanical properties. Lesss than 4.0 ml diffusible hydrogen level. | Download |
| 15 | GM 18 G | E 7018-G-H4 | 495 | 590 | 23 | N/S | AC:DC+ | Excellent Weldability. Tough and crack free joints. | Download |
| 16 | GM 18 SPL | E 7018-1-H4 | 510 | 600 | 30 | 70 at -45°C | AC:DC+ | Ultra Smooth finely rippled weld bead. Less than 4.0 ml diffusible hydrogen level. | Download |
| 17 | GM 18 A1 | E 7018-A1-H4 | 490 | 600 | 26 | N/S | AC:DC+ | Excellent weldabbility. Best suited positional welding. Excellent creep resistant. | Download |
| HEAT RESISTING ELECTRODES / HIGH STRENGTH ELECTRODES (LOW HYDROGEN) | |||||||||
| 18 | GM 80 G | E 8018-G | 510 | 620 | 28 | N/S | AC:DC+ | Excellent toughness and formability. Highly crack resistant joint welding. | Download |
| 19 | GM 80 B2 | E 8018-B2 | 505 | 600 | 20 | N/S | AC:DC+ | Ultra smooth finely rippled bead. Best in class mechanical properties. | Download |
| 20 | GM 80 B6 | E 8018-B6 | 460 | 550 | 19 | N/S | AC:DC+ | Low Hydrogen Basic Iron Powder type electrode ,Design for creap resistant steel with 5 %cr and 0.5 % mo | Download |
| 21 | GM 80 B8 | E 8018-B8 | 460 | 550 | 19 | N/S | AC:DC+ | Basic Coated Low Hydrogen type electrdoe yelding 9 % cr and 1 % mo | Download |
| 22 | GM 80 C1 | E 8018-C1 | 460 | 550 | 19 | 27 at -60°C | AC:DC+ | Hydrogen Controled iron poweder type heavy coated electrdoe ,suitable for medium tensil and low alloy stractural steel | Download |
| 23 | GM 80 W2 | E 8018-W2 | 460 | 550 | 19 | 27 J at -20°C | AC:DC+ | Basic Coated Electrode which gives radiographic quality weld ,Design for low alloy steel,Cupper bearing corresion resistant steel. | Download |
| 24 | GM 90 B3 | E 9018-B3 | 610 | 715 | 20 | N/S | AC:DC+ | Excellent weldability and mechanical properties. | Download |
| 25 | GM 90 G | E 9018-G | 605 | 710 | 20 | N/S | AC:DC+ | Excellent weldability extra low hydrogen, self peeling slag, best in class mechanical properties. | Download |
| 26 | GM 90 M | E 9018 M-H4 | 540 | 620 | 24 | 27 J at -50°C | AC:DC+ | Extra Low Hydrogen. Tough and crack free welded joints. Excellent mechanical properties. | Download |
| 27 | GM 90 D1 | E 9018-D1 | 530 | 620 | 17 | 27 J at -50°C | AC:DC+ | Heavy coated low hydrogen electrdoe suitable for welding of high strength steel | Download |
| 28 | GM 100 D2 | E 10018-D2-H4 | 620 | 725 | 22 | 50 at -50°C | AC:DC+ | Smooth finely rippled weld bead. Excellent impact notch toughness at -50’C. Recommended for critical secuirty welding applications. | Download |
| 29 | GM 100-G | E 10018-G-H4 | 680 | 810 | 18 | N/S | AC:DC+ | Superior weldability, concentrated arc, smooth weld bead, self releasing slag. | Download |
| 30 | GM 110-G | E 11018-G-H4 | 720 | 780 | 16 | N/S | AC:DC+ | Superior weldability, concentrated smooth arc, all positisons, crack free joints. | Download |
| 31 | GM 110-M | E 11018-M-H4 | 710 | 810 | 20 | 45 at -50°C | AC:DC+ | Excellent weldability. Best in class mechanical properties. | Download |
